Blackmagic Design has announced pricing for the upcoming Blackmagic URSA Cine 17K 65.
The new model includes a new large format 65mm format RGBW 17520 x 8040 sensor with larger photo-sites for 16 stops of dynamic range, interchangeable PL, LPL and Hasselblad lens mounts, and industry standard Lemo and Fischer connections. The camera comes with 8TB of high performance storage built in and also includes high speed networking for media upload and syncing to Blackmagic Cloud.
Blackmagic URSA Cine 17K 65 is being demonstrated on the Blackmagic IBC stand and is now available to order from Blackmagic Design resellers from US$29,995.
URSA Cine features a new sensor designed for “incredible quality images” at all resolutions from 4K to a massive 17K. The larger sensor builds on the technology of URSA Mini Pro 12K with larger photo-sites leading to 16 stops of dynamic range. The unique RGBW architecture provides equal amounts of red, green and blue pixels.
The evenly weighted camera body is built with a robust magnesium alloy chassis and lightweight carbon fiber polycarbonate composite skin. Standard Lemo and Fischer connectors let users control the camera remotely while providing power for lens motors and other accessories. Customers also get 12G‑SDI out, 10G Ethernet, USB-C, XLR audio and more.
Customers can quickly switch between PL, LPL, EF and Hasselblad mounts and each mount has contact pins to read lens metadata for monitoring and for use in post production.
The fold out monitor has a large 5″ HDR touchscreen on one side and an external color status LCD on the other. On the right side of the camera, there’s a dedicated assist station with a second 5″ HDR touchscreen which allows crew to work around the camera without needing external monitors. There’s also a dedicated focus puller’s mode.
The 7 pin Lemo and 3 pin Fischer connectors at the front provide record start/stop and 24V power so are ideal for on board accessories such as focus motors. Camera power is provided by a standard 24V 8 pin Lemo connection, plus there’s an additional 2 pin Lemo 12V connection at the rear for lower voltage accessories.
URSA Cine includes a high performance, optical low pass filter that is precisely matched to the sensor. The OLPF also incorporates updated IR filtering that improves far red colour response which, when combined with Blackmagic RAW processing for the URSA Cine, preserves colour and critical image detail for new levels of image fidelity.
URSA Cine is the first digital film camera with ultra fast high capability Cloud Store technology built in. Blackmagic Media Module includes 8TB of storage. The high speed storage lets customers record at the highest resolutions and frame rates for hours and access their files directly over high speed 10G Ethernet. Or customers can use the media they already own with the optional Blackmagic Media Module CF, which has dual CFexpress slots.
Blackmagic Media Dock accelerates post production workflow by making it faster and simpler to start editing and color correction. Mount up to three Blackmagic Media Modules for high speed access to media from multiple URSA Cine cameras all at the same time. The four high speed 10G Ethernet ports allow up to four separate edit workstations to connect directly and it is extremely fast, even when a lot of users are connected at the same time.
URSA Cine supports creating a small H.264 proxy file in addition to the camera original media when recording. This means the small proxy file can upload to Blackmagic Cloud in seconds so media is available back at the studio in real time. “The ability to transfer media directly into the DaVinci Resolve media bin as editors are working is revolutionary and has never before been possible.”
Now customers can live stream from film sets. URSA Cine features a built hardware streaming engine that supports RTMP and SRT streaming to major platforms or directly to clients. Simply connect to the internet via Ethernet, high speed wifi or even connect a 4G or 5G phone for mobile data.
URSA Cine supports the optional Blackmagic URSA Cine EVF to make outdoors and handheld shooting accurate and easy. Customers get an integrated high quality 1920 x 1080 color OLED display with built in proximity sensor, 4 element glass diopter for incredible accuracy with a wide focus adjustment. A built in digital focus chart ensures customers get perfect viewfinder focus setup.
URSA Cine includes an 8-pin Lemo power connector at the back of the camera that works with 24V and 12V power supplies. That means it’s easy to use the camera with existing power supplies, batteries and accessories. URSA Cine comes with a 250W power supply and B Mount battery plate so customers can use a wide range of high voltage batteries from manufacturers such as IDX, Blueshape, Core SWX, BEBOB and more.
Every camera comes in a rugged Pelican case with custom foam cutouts that precisely and securely fit the camera and its accessories. The PL lens mount comes preinstalled on the camera body, plus customers get an active Hasselblad HC lens mount for use with amazing medium format stills lenses. Customers get a 8TB Media Module preinstalled, formatted and ready to record. Customers also get a top handle, antennas for high speed wifi, baseplate, 24V power supply and high voltage B mount battery plate for quick set up.
“In building both URSA Cine models, we wanted to build our dream high end cameras that had everything we had ever wanted,” said Grant Petty, Blackmagic Design CEO, “Blackmagic URSA Cine 17K 65 is the realization of that dream with a massive 65mm image sensor, a body with industry standard features and connections, and seamless integration into high end workflows. There’s been no expense spared in designing this camera and we think it will truly revolutionize all stages of production from capture to post!”
Blackmagic URSA Cine 17K Features
- Cinematic ultra large format 2.2:1 aspect sensor with a massive 16 stops of dynamic range.
- Lightweight, robust camera body with industry standard connections.
- Blackmagic RAW for real time 17K editing.
- Generation 5 Color Science with new film curve.
- High performance OLPF for reduced moire and aliasing.
- High performance Blackmagic Media Module 8TB for recording included.
- Recording media compatible with the Blackmagic Media Dock.
- High speed wifi, 10G Ethernet or mobile data for network connections.
- Built-in RTMP and SRT live streaming.
- Optional Blackmagic URSA Cine EVF.
- Includes DaVinci Resolve Studio for post production.
